Specifications
Specifications
| Grips | Size: S , M , L , XL Bontrager XR Trail Comp, nylon lock-on |
| Handlebar | Bontrager Comp, alloy, 31.8mm, 40mm rise, 780mm width |
| Headset | FSA IS-2, 1-1/8'' top, 1.5'' bottom |
| Pedals | Nylon platform |
| Saddle | Bontrager Verse P3, steel rails |
| Seatpost | Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length Size: M , L , XL Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 450mm length |
| Stem | Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length |
| Brakes | Tektro Gemini SL 4 piston hydraulic brake |
| Brakes Rotor | Tektro, centerlock, 203mm |
| Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10 speed |
| Chain | Shimano LG500, 9/10/11 speed |
| Chainring | FSA, 36T, steel |
| Crankset | FSA Bosch CK-220, 36T ring, 165mm length |
| Rear Derailleur | Shimano CUES U6000 GS |
| Shifters | Shimano U6000, 10 speed |
| Display/Controller | Bosch Purion 200 |
| E Motor | Bosch Performance Line CX (Europe and APAC: 25 km/h, US and ROW: 20 mph / 32 km/h) |
| E Motor Battery | Bosch PowerTube 600Wh, smart system |
| E Motor Charger | Bosch standard 2A, 110V, smart system |
| Fork | Size: S , M , L , XL RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 130mm travel |
| Frame | Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, Mino Link adjustable geometry, adjustable leverage rate, 34.9mm seat tube, ABP, UDH, rack and mudguard mounts, Boost 148, 120 mm travel |
| Frame Material | Alloy |
| Front Travel | 130mm |
| Rear Shock | RockShox Deluxe Select R, 210x50mm |
| Rear Travel | 120mm |
| Accessories | Trek custom fender |
| Approx. Weight | M - 25.58 kg / 56.4 lbs (with TLR sealant, no tubes) |
| Front Hub | Shimano TC500 alloy, centerlock, 110x15mm thru axle |
| Rear Hub | Shimano TC500 alloy, centerlock, 148x12mm thru axle |
| Rims | Size: S Bontrager Line TLR 30, 27.5'' Tubeless Ready, 32-hole, Presta valve Size: S Bontrager Line TLR 30, 27.5'' Tubeless Ready, 28-hole, Presta valve Size: M , L , XL Bontrager Line TLR 30, 29'' Tubeless Ready, 28-hole, Presta valve Size: M , L , XL Bontrager Line TLR 30, 29'' Tubeless Ready, 32-hole, Presta valve |
| Tyres | Size: S Bontrager Gunnison Pro XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40'' Size: M , L , XL Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40'' |
