Trek Marlin 6

SKU: FP_46560
$1,599.00
Shipping calculated at checkout.


Loading locations...

Description

The Marlin 6 is the perfect ride for progressing your skills on the trails. Its updated slacker frame geometry makes it easier to control on descents while the suspension fork takes the edge off bumpy trails. Integrated rack and kickstand mounts make it easy to add accessories to this versatile steed.

- You get real-deal modern mountain bike geometry that keeps handling confident when you're on singletrack, but is versatile enough for use on roads and bike trails too
- Mudguard mounts make it easy to accessorise, so your mountain bike can double as a rugged commuter
- The new Thru-Skew system is safer, simpler and stronger, plus it makes removing the rear wheel for flat fixes a piece of cake
- Internal routing makes it easy to add a dropper post that lets you lower your saddle on the fly for more confident descending
- Marlin models in sizes XXS and XS have a curved top tube and lower standover height that makes it easier for smaller riders to mount and dismount

You want a trail bike that's dialled for building confidence on the dirt, and versatile enough for commuting to work or school.
A lightweight aluminium frame with modern trail riding geometry and internal routing that keeps cables protected and keeps the bike looking sleek. A 100 mm RockShox Judy front suspension fork that cushions rocks, roots and bumps in the trail, 10-speed fuss-free Shimano CUES shifting and the serious stopping power of hydraulic disc brakes.
The Marlin 6 is an ideal trail bike for riders who want to progress on the trail, and want a bike that can keep them rolling off of the trail too.


Will my bike have a curved top tube?
Smaller frames have a top tube that dips down as it approaches the seat tube. This design makes for a lower standover height, which is good for shorter riders because it allows them to straddle their bike more easily. Larger frame sizes have a straight top tube because taller riders with longer legs typically don't have the same issues with standover height.

Fit for every rider
Marlin comes in seven frame sizes to suit riders of any height, and Smart Wheel Size ensures you're on the fastest wheel that fits. The smallest sizes even come with short-reach brake levers and narrower handlebars that give smaller riders better comfort and control.

High tech, high value
Marlin looks and feels great. Its packed with features usually found only on more expensive bikes, like a stylish frame with internal shift cable and brake hose routing, which can help your cables last longer by protecting them from the elements.

Shimano CUES
Inspired by rider demand for trouble-free drivetrain longevity and performance, Shimano CUES offers a new foundation for versatility and durability across a range of both electric and standard bikes. CUES features Shimanos new LINKGLIDE drivetrain technology for significantly increased life on wear items like chain, cassette and chainrings.

Shimano LINKGLIDE
LINKGLIDE technology has been specifically engineered for incredible durability while still delivering smooth and decisive shifting, along with a great pedalling experience. Available exclusively on Shimano CUES drivetrains.

Upgrade your pedals and love your bike more
Pedals are two of the five touchpoints that connect you with your bike, and even though this bike comes with a pair, upgrading to pedals that boost control and grip will greatly improve your ride. See the pedal guide and find the best pedals for your riding style. We recommend flat pedals for simple versatility.

Specifications

    GripsTrek Line Comp, nylon lock-on
    HandlebarSize: XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width Size: S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width Size: M , ML , L , XL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
    HeadsetSemi-integrated, 1-1/8"
    PedalsVP-536 nylon platform
    SaddleBontrager Verse Short, stainless steel rails
    SeatpostSize: XS , S TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm length Size: M TranzX JD-YSI34, 125 mm travel, internal routing, 31.6 mm, 405 mm length Size: ML , L , XL TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm length
    StemSize: XS , S Bontrager Comp, 31.8 mm, 7-degree, 35 mm length Size: M , ML , L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length Size: XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
    Bottom BracketShimano, 73 mm, threaded cartridge, 122.5 mm spindle
    BrakesShimano MT200 hydraulic disc
    Brakes RotorSize: XS , S , M , ML , L , XL Shimano RT26, 6-bolt, 160 mm Size: M , ML , L , XL Shimano RT26, 6-bolt, 180 mm
    CassetteShimano CUES LG300, LINKGLIDE, 11-48, 10-speed
    ChainShimano LG500
    CranksetSize: XS , S , M , ML Shimano U4000, 30T chainring, 170 mm length Size: L , XL Shimano U4000, 30T chainring, 175 mm length
    Rear DerailleurShimano CUES U6000 GS
    ShiftersShimano U6000, 10-speed
    ForkSize: XS , S RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel Size: M , ML , L , XL RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
    FrameSize: XS Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew Size: S , M , ML , L , XL Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
    Approx. WeightM - 15.00 kg / 33.07 lbs
    Front HubFormula DC-20, alloy, 6-bolt, 100 mm
    Rear HubFormula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm
    RimsSize: XS , S , M , ML , L , XL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve Size: M , ML , L , XL Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
    TyresSize: XS , S Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35'' Size: M , ML , L , XL Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35"
